IC ENGINE
- TYPE: V12, 60°, MPI (Multi Point Injection)
- DISPLACEMENT: 6,498 cc (396.5 cu. in)
- BORE X STROKE: 95 mm x 76.4 mm (3.74 in. x 3 in.)
- VALVE PER CYLINDER: 4
- VALVE GEAR: Variable valve timing electronically controlled
- COMPRESSION RATIO: 11.8 +/- 0.2
- MAX. POWER: 780 CV (574 kW) @ 8.500 rpm
- SPECIFIC POWER OUTPUT: 120 CV/l (88.3 kW/l)
- MAX. TORQUE: 720 Nm (531 lb.-ft.) @ 6.750 rpm
- MAXIMUM ENGINE SPEED: 8,700 rpm
- LUBRIFICATION: Dry sump
- EMISSION CLASS: EURO 6 – LEV 3
- EMISSION CONTROL SYSTEM: Catalytic converters with lambda sensors
- COOLING SYSTEM: Water and oil cross-flow cooling system with variable air inlets
- ENGINE MANAGEMENT SYSTEM: Lamborghini Iniezione Elettronica (LIE) with Ion current analysis
ELECTRIC POWER UNIT
- SUPERCAPACITOR VOLTAGE: 48 V
- SUPERCAP POWER DENSITY: 2400 W/kg
- MAX OPERATIVE CURRENT: 600A
- MAX POWER: 34 CV
- MAX TORQUE: 35 Nm
- WEIGHT E-MACHINE + SUPERCAP/ 34 kg
TRANSMISSION
- TRANSMISSION TYPE: 4WD with Haldex generation IV
- GEARBOX: 7 speed ISR, with e-machine installed on the rear wheels output, shifting characteristic depending on drive select mode
- STANDARD: AMT
- CLUTCH: Dry double plate clutch, Ø 235 mm (9.25 in.)
- GEAR RATIOS:
- 1st gear ratio: 3.909
- 2nd gear ratio: 2.438
- 3rd gear ratio: 1.810
- 4th gear ratio: 1.458
- 5th gear ratio: 1.185
- 6th gear ratio: 0.967
- 7th gear ratio: 0.844
- Reverse ratio: 2.929
- Final drive ratio (rear – front): 2.867 – 3.273
PERFORMANCE
- TOP SPEED: km/h 355 (mph 221)
- ACCELERATION 0-100 KM/H (MPH 0-62): 2.8 s
- ACCELERATION 0-200 KM/H (MPH 0-124): 8.6 s
- BRAKING 100-0 KM/H (MPH 62-0): 30 m
BODY AND CHASSIS
- CHASSIS: Carbon fiber monocoque with aluminum front and rear frames
- BODY: Full exterior body and interior trims (rear panels, door panels, tunnel, luggage compartment) in carbon fiber
- MIRRORS: External mirrors heated, electrically adjustable, and foldable
- REAR SPOILER: Rear electronically operated spoiler with 3 positions; completely paneled underbody
WHEELS
- FRONT RIMS: 9″JX20″ ET 17.2
- REAR RIMS: 13″JX21″ ET 51.7
- FRONT TIRES: NEW PIRELLI P ZERO CORSA 255/30 ZR20
- REAR TIRES: NEW PIRELLI P ZERO CORSA 355/25 ZR21
STEERING AND SUSPENSION
- CONTROL SYSTEMS: ESC integrating ABS and TCS with different characteristics according to the driving mode selected
- SUSPENSION TYPE: Pushrod magnetorheological active front and rear suspension with horizontal dampers and springs
- SUSPENSION GEOMETRY: Aluminum double-wishbone fully independent front and rear suspension.
- STEERING SYSTEM: Hydraulic assisted power steering, with 3 different Servotronic characteristics coupled with Lamborghini Dynamic Steering (LDS) and Rear Wheel Steering (RWS), managed by drive select mode
- STEERING WHEEL RATIO 10:1 – 18:1
- STEERING WHEEL turns lock to lock 2.1 – 2.4
- STEERING WHEEL diameter 358 mm
- KERB-TO-KERB TURNING CIRCLE: 11.5 m (37.73 ft.) – average value, variable due to dynamic condition thanks to LRS
BRAKING SYSTEM
- BRAKES: Carbon-ceramic brakes with fixed monoblock calipers in aluminum with 6 pistons (front) and 4 pistons (rear)
- FRONT BRAKES: Carbon-ceramic discs – ventilated with 400 mm diameter and 38 mm thickness
- REAR BRAKES: Carbon-ceramic discs – ventilated with 380 mm diameter and 32 mm thickness
SAFETY
- AIRBAGS: Driver, passenger and side airbags; kneels airbags in selected markets
- PASSIVE SAFETY: Front and rear specific collapsible areas; side protection system
- ACTIVE SAFETY: Electronic Stability Control (integrating ABS and TCS)
DIMENSION
- LENGTH: 4,870 mm (191.73 in.)
- WIDTH (EXCLUDING MIRRORS): 2,099 mm (82.64 in.)
- WIDTH (INCLUDING MIRRORS): 2,265 mm (89.17 in.)
- HEIGHT: 1,139 mm (44.84 in.)
- WHEELBASE: mm 2,700 (in 106,30)
- DRY WEIGHT: 1595 kg (3516 lb)
- TOTAL WEIGHT PERMITTED: 2100 kg (4630 lb)
- WEIGHT DISTRIBUTION: % 43 / 57
- TRACK (front – rear): 1,784 mm (70.23 in.) – 1,709 mm (67.28 in.)
- GROUND CLEARANCE (standard – lifting): 115 ± 2 mm (front with lifting 155 mm)
CAPACITIES
- FUEL TANK: 70 liters
- ENGINE OIL: 13 liters
- ENGINE COOLANT: 25 liters
- LUGGAGE COMPARTMENT: 63 liters
CONSUMPTION
- COMBINED: Pending homologation
- CO2 EMISSIONS: Pending homologation
