Type: Lamborghini Diablo 132 GT1
Years built : 1997
Production : 2
Type of car : Two door coupe, single seater GT race car, horizontally hinged doors
Bodywork : Carbon Fiber
Chassis : Steel chassis, weight : 190 Kg
Designed by : Signes Advanced Technology
Built by : Signes Advanced Technology
Wheelbase : 2695 mm (106 in)
Overall length : 4705 mm (185 in)
Overall width : 2040 mm (80.3 in)
Overall height : 1004 mm (39.5 in)
Front track : 1694 mm (66.6 in)
Rear track : 1670 mm (65.5 in)
Front overhang : 980 mm (38.5 in)
Rear overhang : 1030 mm (40.5 in)
Weight : 1050 Kg. (2500 Lbs)
Distribution : 47/53 % front / rear
Engine type : modified V-12 60 degree, light-alloy block, mid mounted (longitudinal), rear wheel drive
Cyl. Capacity : 5994 cc
Bore & stroke : 87 x 84 mm
Compr. ratio : 11.0:1
Max. power : 655 Bhp at 7500 Rpm
Max. torque : 70 Kg-m at 5500 rmp
Engine weight : 210 Kg. (500 Lbs)
Drive train : 6-Speed sequential gearbox TGTA-200 by Hewland
Brakes : All-wheel Brembo/AP cross drilled/ventilated disk brakes with 6 calipers on the front and 4 calipers on the rear ones.
Front tyre size : Michelin 275/40 – 18, Dunlop 20/655 – 18
Rear tyre size : Michelin 345/35 – 18, Dunlop 330/710 – 18
Wheel type : OZ-Racing aluminium light-alloy central locking type, 18 inch
Clutch : AP Triple plate carbon.
