General
|
|
| Type |
Miura Jota |
| Years built |
1970 |
| Production |
1 units |
| Chassisnr. |
5084 with engine number 30744 |
| Presentation |
Never presented to the public |
| Type of car |
Two door, two seater berlinetta, modified to racing specs |
| Designed by |
Bertone, Marcello Gandini |
| Built by |
Bertone, complete modifications done by Bob Wallace |
Dimensions
|
|
| Wheelbase |
2505 mm / 98.45 in |
| Overall length |
0 mm / 0 in |
| Overall width |
0 mm / 0 in |
| Overall height |
1000 mm / 39.3 in |
| Front track |
1460 mm / 57.38 in |
| Rear track |
1540 mm / 60.52 in |
| Weight |
900 kg / 1985 lbs |
Chassis
|
|
| Structure |
Mainly Avional, an alloy of aluminum and magnesium |
| Body |
Mainly Avional |
| Suspension |
All-independent, parallelogram arms with coil springs, telescopic, adjustable Koni shock absorbers |
| Brakes |
All-wheel ventilated disc brakes |
| Front |
380×35 mm / 14.93 in |
| Steering type |
n.a. |
| Front tire size |
n.a. |
| Rear tire size |
n.a. |
| Type of tire |
Dunlop racing tyres, later Pirelli |
| Front wheel |
9×15 inch |
| Rear wheel |
12×15 inch |
| Type of wheel |
Campagnolo cast magnesium with knock-off’s |
Engine
|
|
| Type |
V-12 60 degree, light-alloy block with gearbox and differential built in the same block and pressed-in liners mid mounted, rear wheel drive |
| Distribution |
Dual overhead camshafts, chain drive, two valves/cyl. |
| Main Bearings |
7 |
| Cyl. Capacity |
3939 cc / 240 ci |
| Bore & stroke |
82 x 62 mm |
| Compr. Ratio |
11.5 |
| Max. power |
440 Bhp at 8500 rpm |
| Max. torque |
403 Nm at 6500 rpm |
| Cooling system |
n.a. |
| Ignition |
Two coils and two Marelli distributors |
| Fuel system |
Dual electric Bendix fuel pumps, 4 tripple-choke Weber 46 IDL carburetors |
| Lubrication |
Dry sump, with two pumps and radiator |
| Electr. system |
12 V |
Drivetrain
|
|
| Type |
Lamborghini five-speed + reverse manual, and ZF self-blokking differential |
| Clutch |
Borg & Beck triple-disc, hydraulically operated |
Performance
|
|
| Top speed |
320 Km/h / 199 Mph |
| 0 – 100 Km/h |
3.60 sec. |
| Standing Km |
19.60 sec. |
Capacities
|
|
| Fuel |
120 Liter / 32 Gallon |
Pricing
|
|
| Current value |
Car has been sold in 1972 for an unknown amount and was crashed beyond repair, a replica was built in 2003 |
